Name:0.18mm FR4 thin PCB
MaterialFR4
Layers2L
Board thickness0.18mm
Solder MaskBlack
Surface Finishedimmersion gold
Email US:info@kartain.com

Product Description Contact Us

Process Capability for Ultra-thin PCB Board
Layers: 1-8L
Material: FR4
Maximum size: 480*1200mm
Minimum line/space: 3mil
Min Board thickness: 0.075mm
copper thickness:1/3OZ-2OZ
Board outline tolerance: ±0.1mm
Thickness tolerance: 2L +/-0.03mm;4L> +/-0.05mm
Minimum drilling hole (mechanical): 0.15mm
Minimum laser hole: 0.1mm
Surface finish:  lead free HASL, immersion gold, immersion tin, immersion silver, plated gold, OSP,
Acceptable file format: all Gerber files, CAM-350, Portal, Pads 2000, CAD, ORCAD, P-CAD, CAM 2000
Quality standards: IPC-A-600F and MIL-STD-105D China GB4558

Packing: inner vacuum packing, outer standard carton box


CONTACT KARTAIN TECHNOLOGY

Kartain is committed to to provide you with exceptional support and satisfaction for your PCB fabrication and PCB assembly needs from QTA prototyping to High volume production.

Our experts are available to consult you for your project. So, call us anytime at 0755-23024958 or  get in touch via email.
